Product Description
Overview
·Material：Nylon 66, 94V-2 certificated by UL. Acid & erosion control,insulate well and not easy to aging、tensile strong.
·Application temperature：-50℃ to 85℃
·Installation temperature：-40℃ to 85℃
·Color：Natural,UV black
Technical Parameters
| Item NO. | L | W(mm) | Max.BundleDIA(mm) | TensileStrength | ||
| Inch | mm | LBS | KGS | |||
| CHS-3×100CRT | 4″ | 100 | 2.5 | 22 | 18 | 8 |
| CHS-4×150CRT | 6″ | 150 | 3.6 | 35 | 40 | 18 |
| CHS-4×200CRT | 8″ | 200 | 3.6 | 53 | 40 | 18 |
| CHS-5×200CRT | 8″ | 200 | 4.8 | 53 | 50 | 22 |
| CHS-5×250CRT | 10″ | 250 | 4.8 | 65 | 50 | 22 |
| CHS-5×300CRT | 11 5/8″ | 300 | 4.8 | 82 | 50 | 22 |
| CHS-5×380CRT | 15″ | 370 | 4.8 | 105 | 50 | 22 |
| CHS-8×300CRT | 11 5/8″ | 300 | 7.6 | 80 | 120 | 55 |
| CHS-8×350CRT | 13 3/4″ | 350 | 7.6 | 90 | 120 | 55 |
| CHS-8×400CRT | 15 3/4″ | 400 | 7.6 | 105 | 120 | 55 |
| CHS-8×500CRT | 19 11/16″ | 500 | 7.6 | 145 | 120 | 55 |
