Stainless Steel Pawl Cable Ties(Marine Cable Ties)

Product Description

Overview

·Material：Nylon 66, 94V-2 certificated by UL. Acid & erosion control,insulate well and not easy to aging、tensile strong.
·Application temperature：-40℃ to 85℃
·Installation temperature：-20℃ to 85℃
·Color：Natural, Black,UV black, other colors are available as requested.
·Feature：The head is embedded with stainless steel,which makes cable ties more stable and durable.

Technical Parameters

Item NO.	L		W (mm)	Max.Bundle Dia.E(mm)	Min.Loop Tensile Strength
Item NO.	Inch	mm	W (mm)	Max.Bundle Dia.E(mm)	LBS	KGS
NZ-3×100	4″	100	3.0	25	18	8
NZ-4×150	6″	150	4.0	35	45	20
NZ-4×200	8″	200	4.0	50	45	20
NZ-4×280	11″	280	4.0	70	45	20
NZ-4×370	14 1/2"	370	4.0	102	45	20
NZ-5×250	10"	250	5.0	65	50	22
NZ-5×300	12"	300	5.0	80	50	22
NZ-5×350	13"3/4"	350	5.0	90	50	22
NZ-5×430	17"	430	5.0	115	50	22
NZ-8×145	5"3/4"	145	8.0	32	120	55
NZ-8×175	7"	175	8.0	42	120	55
NZ-8×200	8"	200	8.0	50	120	55
NZ-8×240	9 1/2"	240	8.0	56	120	55
NZ-8×300	12"	300	8.0	80	120	55
NZ-8×400	15 3/4"	400	8.0	100	120	55
NZ-10×300	12"	300	10.0	80	135	60
NZ-10×350	14"	350	10.0	90	135	60
NZ-10×400	15 3/4"	400	10.0	105	135	60
NZ-10×450	17 3/4"	450	10.0	115	135	60
NZ-10×500	17 11/16"	500	10.0	150	135	60
NZ-10×600	23 5/8"	600	10.0	170	135	60
